High Resolution Oscilloscope

SDS6000A Series

SDS6000A

Bandwidth

2 GHz

Real time sampling rate

10 GSa/s

Channels

4 + EXT

Created with Pixso.
Created with Pixso.
Created with Pixso. Quote
Created with Pixso. Datasheet
Created with Pixso. Video

SDS6000A

SDS6000A

Created with Pixso.

Product Introduction

SIGLENT’s SDS6000A series Digital Storage Oscilloscopes are available in bandwidths of 2 GHz, 1 GHz, and 500 MHz, have a sample rate of 5 GSa/s (10 GSa/s ESR) at each channel, a maximum record length of 500 Mpts, and display up to 4 analog channels + 16 digital channels mixed-signal analysis ability.

Key Features

  • Bandwidth： 500 MHz, 1 GHz, 2 GHz
  • ADC：8-bit
  • Real time sampling rate：5 GSa/s (10 GSa/s ESR) ADC per analog channel
  • Record Length up to 500 Mpts
  • Waveform capture rate up to 750,000 wfm/s (Sequence mode)

Product advantage

Achieve more with SDS6000A oscilloscope

  • 12-bit high-resolution ADC sampling, better presenting waveform details.
  • SDS6000A comes with even more memory depth. 500 Mpts and a hardware-based zoom.
  • The sample rate is up to 5 GSa/s (10 GSa/s ESR) per channel, even when you use all four channels at the same time. No compromises.

Modern form factor balances ease-of-use and desk space

SDS6000A is easy to move around the lab and occupy small desk space. The big 12.1 inch and high resolution touch screen provides intuitive control and clear information for faster debugging.
It is also easily customized, you can choose your favorite channel traces colors, default settings, menu styles, measurement formats and so on. The faster UI response of SDS6000A makes R&D work even more pleasing.

Eye/Jitter analysis

Troubleshoot high-speed digital circuits more effectively using the Jitter Analysis option.
Delivers Eye Diagram and Jitter analysis including jitter decomposition information and more.

Excellent Operability

  • SAP1000 active probe was released with SDS5000X oscilloscope. This time SDS6000A comes with two newly designed active probes. SAP2500 is single ended via SAP2500D is 2.5 GHz differential active probe. With the Eye diagram/ Jitter analysis functions, SDS6000A is more capable in high speed circuits design and signal integrity measurements.
  • · Capacitive touch screen, supports multi-touch gestures, traces can be moved or scaled efficiently by a finger touch
  • · Built-in web server supports remote control over the LAN port using a web browser
  • · External mouse and keyboard support

Triggering and decoding of serial protocols covering various industries

SDS6000A provides a variety of serial protocol triggering and decoding, such as I2C, SPI, UART, CAN, CAN FD, LIN, FlexRay, SENT, I2S, MIL-STD-1553B, Manchester, ARINC429, covering many industries such as embedded, automotive, audio and wireless communication.

Product parameter

View All Parameters
Created with Pixso.

Configure your instrument

Created with Pixso.
Options
Created with Pixso.
Accessories
Created with Pixso. View More

Models

Add to Compare ModelsBandwidthChannelsVertical ResolutionSampling RateMemory DepthCapture Rate Price

Resources

Probe (Standard)
Created with Pixso. Created with Pixso.

Product
Description
SP3150A
SP3150A

Passive probe, 500 MHz bandwidth, 10X attenuation ratio, input impedance of 11pF || 10MΩ, with automatic identification function.

Click to view the probe manual

SP6150A
SP6150A
Passive probe, 1.5 GHz bandwidth, 10X attenuation ratio, input impedance of 1.8pF || 500Ω, with automatic identification function.

Other
Created with Pixso. Created with Pixso.

Probe
Created with Pixso. Created with Pixso.

Product
Description
SP6150A
SP6150A
Passive probe, 1.5 GHz bandwidth, 10X attenuation ratio, input impedance of 1.8pF || 500Ω, with automatic identification function.
SAP2500D
SAP2500D
Active differential probe, bandwidth of 2.5 GHz, attenuation ratio of 10X, differential input impedance of 1pF || 200kΩ, offset range of 8V, SAPBus interface.
Click to view the probe manual.
SAP2500
SAP2500

Active single-ended probe, bandwidth of 2.5 GHz, attenuation ratio of 10X, input impedance of 1.1pF || 1MΩ, offset range of ±12V, SAPBus interface.

Click to view the probe manual

SAP1000
SAP1000

Active single-ended probe, 1 GHz bandwidth, 10X attenuation ratio, input impedance of 1.2pF || 1MΩ, offset range of ±12V, SAPBus interface.

Click to view the probe manual

HPB4010
HPB4010

High voltage probe, DC-40 MHz bandwidth, 1000X attenuation ratio, input impedance 3pF || 100MΩ.

Click to view the probe manual

DPB1300
DPB1300

High voltage differential probe, 50 MHz bandwidth, 50X/500X attenuation ratio, maximum differential voltage ±1300V, differential input impedance 2pF || 10MΩ, BNC interface.

Click to view the probe manual

DPB4080
DPB4080

High voltage differential probe, 50 MHz bandwidth, 10X/100X attenuation ratio, maximum differential voltage 800 V, differential input impedance 1.2pF || 54MΩ, BNC interface.

Click to view the probe manual

DPB5150
DPB5150

High voltage differential probe, bandwidth of 70 MHz, attenuation ratio of 50X/500X, maximum differential voltage of ±1500V, differential input impedance of 2pF || 10MΩ, BNC interface.

Click to view the probe manual

DPB5150A
DPB5150A

High voltage differential probe, 100 MHz bandwidth, 50X/500X attenuation ratio, maximum differential voltage ±1500V, differential input impedance 2pF || 10MΩ, BNC interface.

Click to view the probe manual

DPB5700
DPB5700

High voltage differential probe, 70 MHz bandwidth, 100X/1000X attenuation ratio, maximum differential voltage 7000 v, differential input impedance 2.5pF || 40MΩ, BNC interface.

Click to view the probe manual.

DPB5700A
DPB5700A

High voltage differential probe, 100 MHz bandwidth, 100X/1000X attenuation ratio, maximum differential voltage 7000 v, differential input impedance 2.5pF || 40MΩ, BNC interface.

Click to view the probe manual

SCP5030
SCP5030

Current probe, DC-50 MHz bandwidth, 1X/10X attenuation ratio, maximum input of 30Arms/50Apk, SAPBus interface.

Click to view the probe manual

SCP5030A
SCP5030A

Current probe, DC-100 MHz bandwidth, 1X/10X attenuation ratio, maximum input of 30Arms/50Apk, jaw diameter of 5mm, SAPBus interface.

Click to view the probe manual.

SCP5150
SCP5150

Current probe, DC-12 MHz bandwidth, attenuation ratio of 10X/100X, maximum input of 150Arms/300Apk, jaw diameter of 20mm, powered by 12V adapter.

Click to view the probe manual

SCP5500
SCP5500

Current probe, DC-2 MHz bandwidth, attenuation ratio of 10X/100X, maximum input of 500Arms/750Apk, jaw diameter of 20mm, SAPBus interface.

Click to view the probe manual

CPL5100
CPL5100
Current probe, DC-600 kHz bandwidth, attenuation ratio of 10X/100X, current range of 50mA ~ 100Apk, powered by 12V adapter.
CP4020
CP4020

Current probe, DC-200 kHz bandwidth, attenuation ratio of 20X/200X, maximum input of 20Arms/60Ap-p, 9V adapter for power supply.

Click to view the probe manual

CP4050
CP4050

Current probe, DC-1 MHz bandwidth, 2X/20X attenuation ratio, maximum input 50Arms/140Ap-p, 9V adapter power supply.

Click to view the probe manual

CP4070
CP4070

Current probe, DC-200 kHz bandwidth, attenuation ratio of 20X/200X, maximum input of 20Arms/60Ap-p, 9V adapter for power supply.

Click to view the probe manual.

CP4070A
CP4070A

Current probe, DC-300 kHz bandwidth, attenuation ratio of 10X/100X, maximum input of 70Arms/200Ap-p, 9V adapter for power supply.
Click to view the probe manual

CP6030
CP6030

Current probe, DC-50 MHz bandwidth, 1X/10X attenuation ratio, maximum input of 30Arms/50Apk, jaw diameter of 5mm, powered by 12V adapter.

Click to view the probe manual.

CP6030A
CP6030A

Current probe, DC-100 MHz bandwidth, 1X/10X attenuation ratio, maximum input of 30Arms/50Apk, jaw diameter of 5mm, powered by 12V adapter.

Click to view the probe manual.

CP6150
CP6150

Current probe, DC-12 MHz bandwidth, attenuation ratio of 10X/100X, maximum input of 150Arms/300Apk, jaw diameter of 20mm, powered by 12V adapter.

Click to view the probe manual.

CP6500
CP6500

Current probe, DC-5 MHz bandwidth, attenuation ratio of 10X/100X, maximum input of 500Arms/750Apk, jaw diameter of 20mm, powered by 12V adapter.

Click to view the probe manual.

SAP4000P
SAP4000P
Power rail probe, DC-4 GHz bandwidth, 1.1X attenuation ratio, input dynamic range ±600mV, offset range ±24V, SAPBus interface.
Click to view the probe manual.
SPL2016
SPL2016

16-channel logic probe (hardware), sampling rate and storage depth are determined by oscilloscope, which is suitable for dingyang technology SDS7000A, SDS6000 Pro, SDS6000L, SDS5000X HD, SDS5000X, SDS3000X HD, SDS2000X HD and SDS2000X Plus models.

Click to view the probe manual

Other
Created with Pixso. Created with Pixso.

Trigger/decode Options
Created with Pixso. Created with Pixso.

Product
Description
SDS6000Pro-I2S
SDS6000Pro-I2S

I2S trigger & decode (software)

SDS6000Pro-1553B
SDS6000Pro-1553B
MIL-STD-1553B trigger & decode (software)
SDS6000Pro-FlexRay
SDS6000Pro-FlexRay
FlexRay trigger & decode (software)
SDS6000Pro-CANFD
SDS6000Pro-CANFD
CAN FD trigger & decode (software)
SDS6000Pro-SENT
SDS6000Pro-SENT
SENT trigger & decode (software)
SDS6000Pro-Manch
SDS6000Pro-Manch
Manchester decode (software)
SDS6000Pro-ARINC
SDS6000Pro-ARINC

ARINC429 decode (software)

Analysis Options
Created with Pixso. Created with Pixso.

Bandwidth/Channel Upgrade Options
Created with Pixso. Created with Pixso.

Other
Created with Pixso. Created with Pixso.
